If they show any damage, replace it.

Rear Caliper Dust Boot and Friction Boot Damage


Caliper Fluid Seal Damage
The fluid seal (piston seal) [A] is placed around the piston to maintain clearance between the pad and the disc. If the seal is in a poor condition, it could lead the pad to wear excessively or the ...

Caliper Piston and Cylinder Damage
Visually inspect the pistons [A] and cylinder surfaces [B]. Replace the caliper if the cylinder and piston are badly scores or rusty. Front Caliper [C] Rear Caliper [D] ...
