Kawasaki Ninja Owners Manual: Passenger’s Seat Removal

Seats

...

Rider’s Seat Removal

Remove the bolts and seat cover. A. Bolts B. Seat Cover Remove the mounting bolts and pull off the seat upward. A. Mounting Bolts B. Rider’s Seat ...

Other materials:

Exhaust Butterfly Valve Actuator Removal
NOTICE Never drop the exhaust butterfly valve actuator especially on a hard surface. Such a shock to the actuator can damage it. Remove: Front Seat (see Front Seat Removal in the Frame chapter) Clamp [A] Screws [B] and Washers Slide the covers [A] and loosen the lock nuts [B] ...

Shift Fork/Gear Groove Wear Inspection
Measure the thickness of the shift fork ears [A], and measure the width [B] of the gear grooves. If the thickness of a shift fork ear is less than the service limit, the shift fork must be replaced. Shift Fork Ear Thickness Standard: 5.7 6.0 mm (0.224 0.236 in.) Service Limit: 5.6 mm ...

Rear Wheel Rotation Sensor Removal
NOTICE The wheel rotation sensor should be handled carefully, never struck sharply, as with a hammer, or allowed to fall on a hard surface since the wheel rotation sensor is precision made. Be careful not to get water or mud on the wheel rotation sensor. Do not try to disassemble or repair t ...
