NOTICE
Never drop the intake air temperature sensor especially on a hard surface. Such a shock to the sensor can damage it.
Intake Air Temperature Sensor InstallationUpper Fairing Assembly Disassembly
Remove:
Upper Fairing Assembly (see Upper Fairing Assembly
Removal)
Headlight (see Headlight Removal/Installation in the
Electrical System chapter)
City Light (LED) (see City Light (LED) Removal/Installation
in the Electrical System chapter)
Remove the screws [A], and separate each ...
Starter Motor Assembly
Install the positive brush assy [A] and the starter motor
terminal [B] as shown in the figure.
Replace the O-ring [C] with a new one, and install it.
Install:
Brush Springs [A]
Negative Brush Assy [B]
Turn the stopper side [C] to inside.
Tighten:
Torque - Brush Holder S ...
Lap Counter/Coolant/Intake Air Temperature Meter
This meter shows the coolant temperature,
the intake air temperature or
the lap number. The lap number is displayed
in the stop watch mode, refer to
the “Stop Watch” item in this section.
A. Lap Counter/Coolant / Intake Air
Temperature Meter
The coolant temperature meter and
inta ...
