Sidestand
Sidestand InstallationKIBS Motor Relay Inspection (Service Code b 35)
Check the KIBS motor relay fuse (25 A) [A] (see Fuse
Inspection in the Electrical System chapter)
If the fuse is good, check the wiring continuity as follows.
Disconnect:
Battery Positive Cable (see Battery Removal in the Electrical
System chapter)
KIBS Hydraulic Unit Lead Connector (see ...
Clutch Plate, Wear, Damage Inspection
Visually inspect the friction and steel plates for signs of
seizure, overheating (discoloration), or uneven wear.
Measure the thickness of each friction plate [A] at several
points.
If any plates show signs of damage, or if they have worn
past the service limit, replace them with new on ...
Caliper Installation
Install the caliper and brake hose lower end.
For the front caliper, be sure to install the collars [A].
Replace the washers on each side of hose fitting with new
ones.
Touch the brake hoses [A] to the stopper [B] of the caliper.
Front Calipers [C]
Rear Caliper [D]
Tighten:
To ...
