Balancer
Balancer AssembleDFI System Wiring Diagram (KIBS Equipped Models)
1. Air Intake Solenoid Valve (Other than US, CA and CAL Models)
2. Engine Stop Switch
3. Starter Button
4. Air Switching Valve
5. Stick Coil #1, #2, #3, #4
6. Spark Plugs
7. Intake Air Temperature Sensor
8. Crankshaft Sensor
9. Secondary Fuel Injector #1
10. Secondary Fuel Injector #2
...
Special Tools
Bearing Puller:
57001-135
Head Pipe Outer Race Press Shaft:
57001-1075
Steering Stem Nut Wrench:
57001-1100
Bearing Driver Set:
57001-1129
Steering Stem Bearing Driver, 42.5:
57001-1344
Steering Stem Bearing Driver Adapter,
41.5:
57001-1345
Head Pipe Outer Race Driver, 55:
57001- ...
Crankshaft Sensor Peak Voltage Inspection
NOTE
Be sure the battery is fully charged.
Using the peak voltage adapter [A] is more reliable way
to determine the condition of the crankshaft sensor than
crankshaft sensor internal resistance measurements.
Disconnect the crankshaft sensor lead connector (see
Crankshaft Sensor ...
