This display mode shows the fuel consumption in Liter or Gallon by numerical value counted from the start of measuring to present time.
A. Fuel Consumption
B. “L”
NOTE
Exploded View
AL: Tighten the two clamp bolts alternately two times to ensure even
tightening torque.
G: Apply grease.
R: Replacement Parts
G: Apply grease.
L: Apply a non-permanent locking agent.
R: Replacement Parts
Specifications
...
ESD (Electronic Steering Damper) ECU Communication Error (Service Code 3C,
ZX1000JD/KD)
ESD ECU Communication Line Inspection
When the data (for status of ESD system) is not sent from
the ESD ECU to the meter unit and ECU, the service code
3C is displayed.
The data is sent through the CAN communication line.
The service code 3C is detected with the meter unit.
The FI symbol does ...
Rebound Damping Force Adjustment
The rebound damping force adjuster
is located at the upper end of the rear
shock absorber.
A. Rebound Damping Force Adjuster
B. To increase damping force
C. To decrease damping force
Using a screwdriver turn the rebound
damping force adjuster clockwise
to increase rebound damping or ...
